Wheeled loader 411, JCB
Item code:411&JCB
- 4.4 litre JCB EcoMAX engine with variable geometry turbo
- Heavy duty construction to cope with the toughest jobs
- 4-speed switchable manual/automatic transmission
- Latest Command Plus cab design for ultimate operator comfort
- Innovative hydraulics provide efficient and high performance operation
- DPF-free engine design saves time and money
Request offer
JCB understands that a wheeled loading shovel is a crucial part of any on-site process. For this reason, the new JCB 411 is built on a foundation of quality and reliability. It’s also designed to perform great feats of productivity, offering superb performance without the time-consuming inconvenience of a DPF. Perhaps the biggest change to this wheel loader is the introduction of JCB’s latest Command Plus cab, which means, quite simply, best-in-class comfort, visibility, ergonomics and quietness. Expect superior serviceability and safety too.
Technical specificationsWheeled loader JCB 411
Rated power
81.3 kW
Machine weight
8784 kg
Travel speed
50 km/h
Pin height
3569 mm
FTTL
5091 kg
The ROPS structure on the 411 wheeled loader is redesigned; A pillars are the same width as the rear of the cab, providing a larger interior and panoramic front windscreen. Switches and auxiliary controls are now on the right-hand A-pillar. There are two full colour LCD screens to navigate the operating menus, one of which can double as a monitor for the optional rear-view camera. Using your JCB’s simple, dedicated menu interface is easy with an intuitive optional rotary controller. As standard, the JCB 411 wheeled loading shovel is equipped with heated external mirrors that can be electronically adjusted from inside the cab. Convex mirrors are also available to give the best possible field of vision. An all-new air venting system boasts nine demisting vents and six operator vents to maintain visibility and operator comfort at all times. It also operates at a reduced noise level. All controls are seat-mounted, even moving with the seat suspension. You can also select the control system that’s best for your operators: choose from single lever joystick or multi-lever configurations, all using electro-hydraulics for the ultimate in precision. After extensive research into operator ergonomics, we’ve devised the Command Driving Position, which boasts the very optimal control layout for a multitude of different driver shapes and sizes.
