Tedder KUBOTA TE 6568, Kubota
Item code:TE6568&KUB
- Maintenance-free oil-immersed gearbox
- Maintenance-free driveline with new HexaLink clutches and u-joints
- Strong chassis design with V headstock, fully enclosed mainframe and new alu rails
- Double acting cylinder support unfolding in all conditions and positions
- New hydraulic headland kit for easily lift and lowering at headlands
Request offer
ProLine tedder for midrange farm
Theoretical capacity 5,4 ha/h
Theoretical capacity 5,4 ha/h
Technical specificationsProfiLine tedder for midrange farms
Theoretical capacity 5,4 ha/h
Connection to 3-p linkage CAT2
Maintenance-free oil-immersed gearbox
Maintenance-free driveline with new HexaLink clutches and u-joints
Strong chassis design with V headstock, fully enclosed mainframe and new alu rails
Double acting cylinder support unfolding in all conditions and positions
New hydraulic headland kit for easily lift and lowering at headlands
HexaLink provides the option fold arms into very compact transport and storage dimensions
U-joints provides extremely accurate and reliable power transmission where pressure is highest
Working width: 6,8m
Width, working position: 7,15m
Transport width: 2,92m
Transport length: 2,2m
Storage height: 3,52m
Weight: 900 kg
Hitch: CAT2
No of rotors: 6
No of tine arms per rotor: 6
Wheels (rotor): 16x6,50-8
Oscillation damper/integral lock: +
Adjustment of spreading angle: +
Min power requirement 60 hp
As optional equipment available (not included in price):
* Front wheel (16x6.50-8)
* Tandem axle
* Warning panels and lighting
Warranty 2 years
Pictures are illustrative and for non-contractual use
Working width
6,8m
Width, working position
7,15m
Transport width
2,92m
Transport length
2,2m
Storage height
3,52m
Capacity, theor.
5,4 ha/h
Weight
900 kg
Hitch
CAT2
No of rotors
6
No of tine arms per rotor
6
Wheels (rotor)
16x6,50-8
Oscillation damper/integral lock
+
Adjustment of spreading angle
+
Theoretical capacity 5,4 ha/h
Connection to 3-p linkage CAT2
Maintenance-free oil-immersed gearbox
Maintenance-free driveline with new HexaLink clutches and u-joints
Strong chassis design with V headstock, fully enclosed mainframe and new alu rails
Double acting cylinder support unfolding in all conditions and positions
New hydraulic headland kit for easily lift and lowering at headlands
HexaLink provides the option fold arms into very compact transport and storage dimensions
U-joints provides extremely accurate and reliable power transmission where pressure is highest
Working width: 6,8m
Width, working position: 7,15m
Transport width: 2,92m
Transport length: 2,2m
Storage height: 3,52m
Weight: 900 kg
Hitch: CAT2
No of rotors: 6
No of tine arms per rotor: 6
Wheels (rotor): 16x6,50-8
Oscillation damper/integral lock: +
Adjustment of spreading angle: +
Min power requirement 60 hp
As optional equipment available (not included in price):
* Front wheel (16x6.50-8)
* Tandem axle
* Warning panels and lighting
Warranty 2 years
Pictures are illustrative and for non-contractual use
