Rake KUBOTA RA 2076, Kubota
Item code:RA2076&KUB
- Strong carrier frame for stable raking performance and high ground clearance
- Maintenance friendly oil-immersed gearbox
- Actively steered wheels and headstock geometry allow sharp 80° turns
- TerraLink Quattro ground contour following system with adaptation in 3 dimensions
Request offer
CompactLine twin rotor rake
Carried Center Delivery
Theoretical capacity 8,4 ha/h
Carried Center Delivery
Theoretical capacity 8,4 ha/h
Technical specificationsCarried Center Delivery
CompactLine twin rotor rake
Theoretical capacity 8,4 ha/h
Strong carrier frame for stable raking performance and high ground clearance
Maintenance friendly oil-immersed gearbox
Actively steered wheels and headstock geometry allow sharp 80° turns
TerraLink Quattro ground contour following system with adaptation in 3 dimensions
Working width adjustable: 7,00-7,80 m
Transport width: 2,80 m
Transport length: 5,90 m
Parking height: 3,45/4,10 m
Theoretical capacity: 8,4 ha/h
Weight: 1640 kg
Rotor diameter: 3,35 m
No of rotors: 2
No of arms per rotor: 11
No of double tines per arm: 4
Tine diameter: 9 mm
Height adjustment: mechanical
Tyres (rotor):16x6,50-6
Tandem axle type: fixed, optional
Carrying frame tyres: 10.0/75-15.3
Hydraulically width adjustment
Swath width appr. 1,30-1,90 m
Free float valve needed
Min power requirement 60 hp
Manufactured in Czech
Warranty 2 years
Pictures are illustrative and for non-contractual use
Working width
7,00/7,80 m
Transport width
2,80 m
Transport length
5,90 m
Parking height
3,45/4,10 m
Theoretical capacity
8,4 ha/h
Weight
1640 kg
Rotor diameter
3,35 m
No of rotors
2
No of arms per rotor
11
No of double tines per arm
4
Tine diameter
9 mm
Height adjustment
mechanical
Tyres (rotor):16x6,50-6
Tandem axle type
fixed, optional
Carrying frame tyres
10.0/75-15.3
Detachable tine arms
+
CompactLine twin rotor rake
Theoretical capacity 8,4 ha/h
Strong carrier frame for stable raking performance and high ground clearance
Maintenance friendly oil-immersed gearbox
Actively steered wheels and headstock geometry allow sharp 80° turns
TerraLink Quattro ground contour following system with adaptation in 3 dimensions
Working width adjustable: 7,00-7,80 m
Transport width: 2,80 m
Transport length: 5,90 m
Parking height: 3,45/4,10 m
Theoretical capacity: 8,4 ha/h
Weight: 1640 kg
Rotor diameter: 3,35 m
No of rotors: 2
No of arms per rotor: 11
No of double tines per arm: 4
Tine diameter: 9 mm
Height adjustment: mechanical
Tyres (rotor):16x6,50-6
Tandem axle type: fixed, optional
Carrying frame tyres: 10.0/75-15.3
Hydraulically width adjustment
Swath width appr. 1,30-1,90 m
Free float valve needed
Min power requirement 60 hp
Manufactured in Czech
Warranty 2 years
Pictures are illustrative and for non-contractual use
