Mower KUBOTA DM 3087, Kubota
Item code:DM3087&KUB
- All Kubota mowers are equipped with Triangular Counter-Rotating Discs, 3 blades per disc for constant cutting
- NonStop BreakAway
- The centre suspension provides an even weight distribution across the entire mowing width, and a constant, faster and more precise adaptation to ground contours
Request offer
Fully welded cutterbar design
Butterfly mower
Fast changeable knives
For tractors from 140hp and upwards
Very low power consumption and noise level - thanks to specially designed cutterbar bearings and transmission details
Hydraulic lift
Butterfly mower
Fast changeable knives
For tractors from 140hp and upwards
Very low power consumption and noise level - thanks to specially designed cutterbar bearings and transmission details
Hydraulic lift
Technical specificationsButterfly mower with fast changeable knives
Hitch CAT 2/3
All Kubota mowers are equipped with Triangular Counter-Rotating Discs, 3 blades per disc for constant cutting - clean cut, less wear for blades
Fully welded cutterbar design, no bolt connections
Very low power consumption and noise level - thanks to specially designed cutterbar bearings and transmission details
Mowing units positioned very close to the tractor ensure gravity point close to the tractor
Cutting width 8,7 m
Transport width <3 m
Transport height <4 m
PTO 1000 rpm, overrun clutch + friction clutch
16 discs each with 3 blades
Cutting height 30-60 mm
Mowing angle: -15/+15
BreakAway, NonStop, spring loaded auto reset
Hydraulic lift on headlands up to 400 mm
Supplied with two mounting options of the mowing section, what ensures optimal overlap between a front and rear mounted unit
Vertical Parking Stand
Swath discs (RH)
Hydraulic lift
100° Vertical Transport Position
Weight 1327 kg
Power requirement min 140 hp
No of hydraulic outlets: 2D
From optional equipment are included in price:
* high cut skids 40mm
* protection cutterbar-end 2 pcs
As optional electric lift control joystick available
Optional hydraulic ground pressure adjustment
Manufactured in Denmark
Warranty 2 years
Pictures are illustrative and for non-contractual use
Cutting width
8,7 m
Transport width
less than 3 m
Transport height
less than 4 m
PTO
1000 rpm
Hitch
CAT2/3
Power requirement min.
140 hp
No of discs
16
No of knives
48
Mowing angle
-15/+15
Breakaway
NonStop
Overrun clutch
+
Friction clutch
+
Hitch CAT 2/3
All Kubota mowers are equipped with Triangular Counter-Rotating Discs, 3 blades per disc for constant cutting - clean cut, less wear for blades
Fully welded cutterbar design, no bolt connections
Very low power consumption and noise level - thanks to specially designed cutterbar bearings and transmission details
Mowing units positioned very close to the tractor ensure gravity point close to the tractor
Cutting width 8,7 m
Transport width <3 m
Transport height <4 m
PTO 1000 rpm, overrun clutch + friction clutch
16 discs each with 3 blades
Cutting height 30-60 mm
Mowing angle: -15/+15
BreakAway, NonStop, spring loaded auto reset
Hydraulic lift on headlands up to 400 mm
Supplied with two mounting options of the mowing section, what ensures optimal overlap between a front and rear mounted unit
Vertical Parking Stand
Swath discs (RH)
Hydraulic lift
100° Vertical Transport Position
Weight 1327 kg
Power requirement min 140 hp
No of hydraulic outlets: 2D
From optional equipment are included in price:
* high cut skids 40mm
* protection cutterbar-end 2 pcs
As optional electric lift control joystick available
Optional hydraulic ground pressure adjustment
Manufactured in Denmark
Warranty 2 years
Pictures are illustrative and for non-contractual use
