- 35.6 kW diesel or 43 kW LPG engine choice (or 46 kW diesel on the High Lift option)
- 3000 kg lift capacity and 4m lift height (4 m for 4WD option or 5.15 m for High Lift option)
- Easily-accessible components and service check areas
- High Lift option for increased lift height
- 2000kg lift capacity at 2m
- Full free lift as standard, approximately 1450mm.
The TLT30 counterbalance forklift is a strong and exceptionally versatile performer weighing up to 5380 kg. These industrial forklifts have a choice of diesel (30D 2x4) or LPG (30G 2x4) engines, High Lift (30D HL 2x4) model and even 4WD (30D 4x4). Their maximum lift capacity is 3,000 kg with maximum lift height of 5.15m and a maximum forward reach of 3.32m. The High Lift model is powered by the new Tier 4/Stage IIIB JCB Diesel by Kohler 46kW (62HP) engine. The JCB 30D 2wd and 4wd are powered by the Perkins 37 kW (50 HP) diesel engine. The 30G is powered by the GM 43 kW (57 HP) LPG engine. Our unique telescopic boom offers many benefits. Unrivalled visibility is achieved by the Teletruk’s side arm, which means there is no obstructive mast, improving site safety. The machine’s forward reach gives the ability to load from a single side, reducing double-handling and keeping operators clear of hazardous environments. As a result, 50% less loading space is required which is welcome in congested yards. 111 degrees of carriage rotation makes handing unpalletised goods much easier and safer.
Rated power
37 kW
Machine weight
5100 kg
Travel speed
20 km/h
Lift height
4,0 m
Lift capacity
3000 kg
Every effort has been made to enhance the ergonomics of the Teletruk, ensuring superb operator comfort throughout the working day and enabling you to get the maximum productivity out of this uniquely versatile machine. The controls themselves are ergonomically designed with everything in easy reach and a display that is clearly viewed in any light. The JCB Teletruk also features a multifunctional control lever. The Teletruk offers several cab choices, from simple canopy to fully glazed and low cab option, providing the most comfortable working conditions whatever the climate or conditions.
