The Tomahawk® 45 plasma cutter is portable enough to take with you to any job site. Connect the compressed air, grab the torch and start cutting right away.
Maximum cutting power 20mm (recommended up to 16mm).
Functions:
• TFT 2.8” screen – for a simpler and more user-friendly user interface.
• Continuous output control – suitable arc for different material thicknesses.
• "Touch Start" starting system - reliable plasma arc starting without high frequency.
• Rapid Arc Restrike - rapid cutting of gaps.
• Pressure regulator on the front panel - makes it easy to set the air flow rate without starting the plasma arc.
• Gouging and grid modes (adjustable grid time).
• New design of electrodes and nozzles save money in the long run.
• Additional safety – our consumables installation system detects correct installation of consumables and torch.
• Lightweight and portable – easily carried by one person.
• Motor Drive Compatible – The Tomahawk® 45 Plasma Cutter is portable enough to take with you to any job site. Connect the compressed air, grab the torch and start cutting right away.
• Select a suitable generator to power the Tomahawk® in remote locations.
Technical specifications:
Supply voltage 230V, 1-phase,
Current strength 15-45A,
Duty cycle 45A@45%, 30A@100%.
Weight 11.1 kg.
Dimensions 385x215x480mm.
Air requirement 200l/min +/- 10% @ 5.0-6.0bar.
The set includes:
Input cable, 6m manual torch LC45, earthing clamp and cable, consumable parts of the torch, built-in water separator.
2-year warranty.
All pictures and videos are illustrative.
